| 参数 | Specifications | 技术指标 Technique data | |||||||||
| 压力范围 | Measuring ranges | 0~1.0…1.6…3.0…10…20… 40…50...60... 80…90…100MPa | |||||||||
| 过载压力 | Overload pressures | 200%F.S 150%F.S 150%F.S | |||||||||
| 破坏压力 | Burst pressures | 500%F.S 300%F.S 200%F.S | |||||||||
| 工作方式 | Operational Mode | 表压，绝压 | |||||||||
| 测量介质 | Measuring Media | 对不锈钢304和316L不腐蚀的气、液体 | |||||||||
| 开关量输出 | Type | PNP or NPN | |||||||||
| 输出信号 | Output signal | 4~20mA | |||||||||
| 工作电压 | Operating voltage | 24VDC(±4VDC) | |||||||||
| 显示 | Display | 4-digit LED | |||||||||
| 综合精度 | Accuracy | ±0.5%F.S(典值) | |||||||||
| 长期稳定性 | Long-term drift | ≤±0.3%FS/ 年（典值） | |||||||||
| 工作温度范围 | Operating temperature range | -25~+80℃ | |||||||||
| 漏电流 | Leakage current | ≤1mA | |||||||||
| 绝缘阻抗 | Insulation resistance | ≥100MΩ(100VDC) | |||||||||
| 耐振性能 | Vibration resistance | IEC 60068-2-6 (5…2000Hz, 20g) | |||||||||
| 耐冲击性 | Shock resistance | IEC 60068-2-27 (50g, 11ms) | |||||||||
| 抗干扰 | EMC proof | IEC 61000-6-2/3/4 | |||||||||
| 外壳材质 | Material | 304 | |||||||||
| 防护等级 | IP protection | IP65 | |||||||||
