| 参数 | Specifications | 技术指标 Technique data | |||||||||
| 压力范围 | Measuring ranges | 0～0.5...1.0...1.5...3...5MPaD | |||||||||
| 过载压力 | Overload pressures | 200%F.S | |||||||||
| 破坏压力 | Burst pressures | 500%F.S | |||||||||
| 测量介质 | Measuring Media | 空气、液压油、润滑油等气体、液体 | |||||||||
| 输出信号 | Output signal | PNP 常开、常闭 NPN 常开、常闭 | |||||||||
| 工作电压 | Operating voltage | 24VDC(16~32VDC) | |||||||||
| 综合精度 | Accuracy | ±0.5%F.S(典值) ±1.0%F.S(最大值) | |||||||||
| 长期稳定性 | Long-term drift | ≤±0.2%FS/ 年（典值） | |||||||||
| 环境温度 | Ambient temperature | -40~+85℃ | |||||||||
| 介质温度 | Medium temperature | -30℃～100℃ | |||||||||
| 绝缘阻抗 | Insulation resistance | ≥200MΩ/200VDC | |||||||||
| 耐振性能 | Vibration resistance | IEC 60068-2-6 (5…2000Hz, 20g) | |||||||||
| 耐冲击性 | Shock resistance | IEC 60068-2-27 (50g, 11ms) | |||||||||
| 电磁兼容 | EMC proof | IEC 61000-6-2/3/4 | |||||||||
| 防护等级 | IP protection | IP65、IP67 | |||||||||
