| 参数 | Specifications | 技术指标 Technique data | |||||||||
| 压力范围 | Measuring ranges | 0～0.8...1.0...1.6...3...10...40...50...60...100MPa | |||||||||
| 过载压力 | Overload pressures | 200%F.S 150%F.S | |||||||||
| 破坏压力 | Burst pressures | 500%F.S 200%F.S | |||||||||
| 工作方式 | Operational Mode | 表压、绝压、密封表压 | |||||||||
| 测量介质 | Measuring Media | 对不锈钢不腐蚀的气体、液体 | |||||||||
| 输出信号 | Output signal | (4～20)mA | |||||||||
| 工作电压 | Operating voltage | 28VDC (16～32VDC) | |||||||||
| 综合精度 | Accuracy | ±0.5%F.S ( 典型值 ) | |||||||||
| 长期稳定性 | Long-term drift | ≤±0.2%F.S/year ( 典型值 ) | |||||||||
| 环境温度 | Ambient temperature | -55℃～85℃ | |||||||||
| 介质温度 | Medium temperature | -55℃～150℃（ 可选 ） | |||||||||
| 绝缘阻抗 | Insulation resistance | ≥200MΩ/200VDC | |||||||||
